| Physical |
Size (HxWxD): |
29x34x16 ±0.5 mm / 1.34x1.11x0.63 ±0.02 inch |
| Weight: |
18 ±1 g / 0.63 ±0.04 oz |
| Screw terminals max torque: |
0.4 Nm / 3.5 lbin |
| Conductor cross section: |
0.2 to 2.5 mm² / 24 to 14 AWG (solid, stranded, and bootlace ferrules) |
| Conductor stripped length: |
6 to 7 mm / 0.24 to 0.28 in |
| Mounting: |
Wall box |
| Shell material: |
Plastic |
| Shell color: |
Red, C-3%; M-100%; Y-70%; K-12% |
| Connectors color: |
Grey (Mouse Grey) |
| |
| Environmental |
Ambient working temperature: |
-20 °C to 40 °C / -5 °F to 105 °F |
| Humidity: |
30 % to 70 % RH |
| Max. altitude: |
2000 m / 6562 ft |
| |
| Electrical |
Power supply: |
110 - 240 V~ |
| Relay: |
NO contact, 1-pole, µ contact |
| External protection: |
Tripping characteristic B or C,
max. 10A max. rated current,
min. 6 kA interrupting rating,
energy limiting class 3 |
| |
| Output circuits ratings |
Max. switching voltage: |
240 V~ |
| Max. switching current: |
8A/240 V~ |
| Power measurement: |
Yes |
| Voltage protection / Cutoff: |
Yes |
| Current protection / Cutoff: |
Yes |
| Max power protection / Cutoff: |
Yes |
| |
| Sensors, meters |
Internal-temperature sensor: |
Yes |
| |
| Wi-Fi |
Protocol: |
802.11 b/g/n/ax |
| RF band: |
2412 - 2472 МHz |
| Max. RF power: |
< 20 dBm |
| Range: |
Up to 30 m / 100 ft indoors and 50 m / 160 ft outdoors (Depends on local conditions) |
| |
| Bluetooth |
Protocol: |
5.0 |
| RF band: |
2402 - 2480 MHz |
| Max. RF power: |
< 4 dBm |
| Range: |
Up to 10 m / 33 ft indoors and 30 m / 100 ft outdoors (Depends on local conditions) |
| |
| Zigbee |
Protocol: |
802.15.4 |
| RF bands: |
2400 to 2483.5 MHz |
| Max. RF power: |
< 20 dBm |
| Range: |
Up to 100 m / 328 ft indoors and 300 meters / 984 ft outdoors (Depends on local conditions) |
| |
| Microcontroller unit |
CPU: |
ESP-Shelly-C68F |
| Flash: |
8MB |
| |
| Firmware capabilities |
Schedules: |
20 |
| Webhooks (URL actions): |
20 with 5 URLs per hook |
| Scripting: |
Yes |
| MQTT: |
Yes |
| |
