| Physical |
Size (HxWxD): |
94x19x69 ±0.5 mm / 3.70x0.75x2.71 ±0.02 in |
| Weight: |
63 ±1 g / 2.22 ±0.05 oz |
| Mounting: |
DIN rail |
| Screw terminals max torque: |
0.4 Nm / 4.43 lbin |
| Conductor cross section: |
0.5 to 2.5 mm² / 20 to 14 AWG (solid, stranded and bootlace lugs) |
| Conductor stripped length: |
6 to 7 mm / 0.24 to 0.28 in |
| Shell material: |
Plastic |
| Color: |
White |
| |
| Environmental |
Ambient temperature: |
-20 °C to 40 °C / -5 °F to 105 °F |
| Humidity: |
30 % to 70 % RH |
| Max. altitude: |
2000 m / 6562 ft |
| |
| Electrical |
Power supply voltage AC: |
100 - 260 V, 50/60 Hz |
| Power supply voltage DC: |
N/A |
| Power consumption: |
< 3 W |
| |
| Output circuits ratings |
Max switching voltage AC: |
240 V |
| Max switching voltage DC: |
N/A |
| Max switching current: |
2 A |
| |
| Sensors, meters |
Internal-temperature sensor: |
Yes |
| Voltmeter (RMS): |
100 - 260 V |
| Voltmeters accuracy: |
±1 % |
| Ammeters (RMS via CT): |
0 - 50 A |
| Ammeters accuracy: |
±1 % (5 - 50 A), ±2 % (0 - 5 A) |
| Power and energy meters: |
- Active and apparent power
- Active and apparent energy
- Power factor
|
| Measurement data storage: |
At least 60 days of 1 min data resolution |
| Data export: |
- CSV for PQ recorded values
- JSON format export through RPC
|
| |
| Radio |
RF band: |
2400 - 2495 MHz |
| Max. RF power: |
<20 dBm |
| Wi-Fi protocol: |
802.11 b/g/n |
| Wi-Fi Range: |
Up to 30 m / 100 ft indoors and 50 m / 160 ft outdoors
(Depends on local conditions) |
| Bluetooth Protocol: |
4.2 |
| Bluetooth Range: |
Up to 10 m / 33 ft indoors and 30 m / 100 ft outdoors
(Depends on local conditions) |
| |
| MCU |
CPU: |
ESP32-D0WDQ6 |
| Flash: |
16 MB |
| |
| Firmware capabilities |
Webhooks (URL actions): |
20 with 5 URLs per hook |
| Scripting: |
Yes |
| MQTT: |
Yes |
| CoAP: |
No |
| |
