| Physical |
Size (HxWxD): |
37x42x15 ±0.5 mm / 1.46 x 1.65 x 0.59 ±0.02 in |
| Weigh: |
105 g / 3.70 oz |
| Shell material: |
Plastic |
| Screw terminals max torque: |
0.1 Nm / 0.89 lbIn |
| Conductor cross section: |
max. 1 mm² / 17 AWG |
| Conductor stripped length: |
4.5 mm / 0.18 in |
| Color: |
Black |
| |
| Environmental |
Ambient temperature: |
-20 °C to 40 °C / -5 °F to 105 °F |
| Humidity |
30 % to 70 % RH |
| Max. altitude |
2000 m / 6562 ft |
| |
| Electrical |
Power supply voltage AC: |
N/A |
| Power supply voltage DC: |
3.3 V (from Shelly plus device) |
| Power consumption: |
< 0.5 W (without sensors) |
| |
| Output circuits ratings |
VCC max. current: |
10 mA |
| VREF OUT max. current: |
1 mA |
| VREF+R1 OUT resistor |
10 kΩ |
| |
| Shelly Plus device firmware capabilities |
Shelly Plus Addon supporting devices: |
Shelly Plus devices:
- Shelly Plus 1
- Shelly Plus 1PM
- Shelly Plus 1 UL
- Shelly Plus 1PM UL
- Shelly Plus 2PM
- Shelly Plus 2PM UL
- Shelly Plus i4
- Shelly Plus i4DC
- Shelly Plus 0-10V Dimmer PM
- Shelly Plus RGBW PM
Shelly Gen3 devices:
- Shelly 1 Gen3
- Shelly 1PM Gen3
- Shelly 2PM Gen3
- Shelly Shutter
- Shelly i4 Gen3
- Shelly DALI Dimmer Gen3
- Shelly Dimmer 0/1-10V PM Gen3
- Shelly EM Gen3
Shelly Gen4 devices:
- Shelly 1 Gen4
- Shelly 1PM Gen4
- Shelly 2PM Gen4
|
| Temperature reading: |
Depends on the DS18B20 or DHT22 sensors |
| Humidity reading: |
Depends on the DHT22 sensor |
| Digital input: |
-15 V to 0.5 V (True) / 2.5 V to 15 V (False)* |
| Analog input range: |
0 to 100% |
| Analog input report threshold: |
1%** |
| Voltmeter range: |
0 to 10 V |
| Voltmeter report threshold: |
0.1 V** |
| Analog input / Voltmeter accuracy |
Better than ±5% |
| |
|
| |
